There’s nothing grizzled about the sleek looks of our lightest, most integrated URS, a bike with all the performance a dedicated gravel rider needs. Its gravel-conquering Premium Carbon frameset boasts ICS and MTT technologies, plus epic practicality from multiple mounts, Gravel+ geometry and large tire clearance. Specced with a SRAM Rival eTap AXS drivetrain and Eagle cassette that ramp up its climbing capabilities, and the DT Swiss G1800 Spline wheelset that roll confidently over the terrain, this gravel bike is your key to outdoor freedom.
Gravel+ Geometry
Optimized for a modern, aggressive gravel riding style. URS features a slack 70° head angle to create a long front-end and wheelbase for incredible stability.
Micro Travel Technology (MTT) Stays
A lightweight and minimalist suspension system that adds 10mm of travel for perfect power transfer and control on the most challenging terrain.
Tuned Compliance Concept (TCC) Gravel
The highest level of compliance through a dedicated carbon layup, D-shape seatpost and Micro Travel Technology.
ICS MTT x Redshift Suspension Stem
Utilizing durable cartridge bearings for rotation, with suspension provided by two elastomers positioned inside the stem body. Each elastomer is easily exchangeable, allowing for ride customization, depending on weight, riding style and terrain, with an additional elastomer preventing hard top-outs. Fully compatible with integrated cockpit technology framesets, for clean aesthetics and extended durability.
Top Tube Mount
Mounting option for bolt-on top-tube bags and accessories.
Versatile Fork
45mm clearance, 160mm flat mount (a clean mounting solution for bigger rotors), hub-dynamo cable routing and compatible with Fox 32 SC AX suspension fork.
Integrated Protections
Protections on fork dropouts, downtube and chainstays.
SPECIFICATIONS
Frame
URS 01 Premium Carbon with Micro Travel Technology Tuned Compliance Concept Gravel; Gravel+ Geometry; ICS Technology Stealth Cable Routing ; Fender and Rack Mounts; PF86 Bottom Bracket; Flat Mount Disc; 12x142mm Thru-Axle
Fork
URS 01 Premium Carbon with Tuned Compliance Concept Gravel; ICS Technology Integrated Brake & Hub Dynamo Routing ; Fender Mounts; Flat Mount Disc; 12x100mm Thru-Axle
Seatpost
URS 01 Premium Carbon D-Shaped Seatpost; 0mm Offset
Handlebar
Easton EA70 AX
Stem
ICS MTT x Redshift Suspension Stem - Integrated Cockpit Design
Saddle
WTB SL8
Crankset
SRAM RIVAL 1 AXS 38T
Cassette
SRAM XG 1275 EAGLE 10-52T
Chain
SRAM Gx Eagle 12 Speed
Rear Derailleur
SRAM Gx Eagle AXS
Shifters
SRAM Rival eTap AXS
Brakes
SRAM Rival eTap AXS HRD - Centerline Rotors (180/160)
Rims
DT Swiss G1800 Spline - 25mm
Hubs
DT Swiss 370 Spline Disc
Tyres
WTB Raddler - 40mm
